AOS OVENS - Service Manual
(595889300 – ENG)
APPENDIX B – CONTACTORS DIAGRAM
100% 1/2 100% 1/2 100% 1/2
HOT AIR COMBI STEAM
KS KS KS
K1 K1 K1
K2 K2 K2
K3 K3 K3
K4 K4 K4
Contactors used on AOS061E_, AOS101E_, AOS102E_
100% 1/2 100% 1/2 100% 1/2
HOT AIR COMBI STEAM
KS KS KS
K1 K1 K1
K2 K2 K2
K3 K3 K3
K4 K4 K4
K5 K5 K5
K6 K6 K6
K7 K7 K7
K8 K8 K8
Contactors used on AOS201E_, AOS202E_
File: AOS service manual (ENG).008 ©Copyright 2002 by Electrolux Professional P.20/40
