DOC. NO. 5956.65J.00 P. 25 / 174
EFS - Dishwashing Systems Platform
Electrolux Professional
STEP 1 - FITTING THE TUBE
1. Position the roller. 2. Insert the tube of the suction part, turning the roller
clockwise.
3. Keep the tube in the seat in the housing and
continue turning the roller clockwise, being
careful not to damage the tube.
4. Keep the tube in the seat in the housing and con-
tinue turning the roller clockwise.
5. Turn the roller a full 360°. 6. Make sure to fit the union in the special seat (deliv-
ery).
