DOC. NO. 5956.65J.00 P. 7 / 174
EFS - Dishwashing Systems Platform
Electrolux Professional
4 DETERGENT AND RINSE AID DOSAGE
In this paragraph is explained how to set the working time for the detergent and rinse aid dispensers.
For each dispenser there are two parameters: the initial time and the time during cycle execution.
4.1 General Parameters
How change the duration:
• Switch OFF and switch ON the dishwasher;
• Enter into the USER SETTING mode by pressing and hold down ON/OFF and CYCLE_1 keys for at least five sec-
onds the display shows (Figure 17);
• Press CYCLE_INFINITE. The display shows alternatively the symbol dIn and the duration in seconds (Figure 18) and
(Figure 19) ;
• NOTE: If User Interface v.3.00 tank led is on if value correspond to factory default ( Default 1 - HOOD TYPE).
• Use CYCLE_1 key to decrease the duration and CYCLE_2 key to increase (Figure 19);
• After settled the duration press CYCLE_INFINITE key to store value
. The display shows the next parameter
(Figure 20) and the corresponding value (Figure 21);
• In the same way is possible to change the other duration; when finished switch OFF and switch ON.
Sym. Parameter Description Unit Min Max Factory Default
Initial Detergent Dosage (during filling tank) [s] 0 240 90
Initial Rinse Aid Dosage (starts when tank filled) [s] 0 180 10
Detergent Dosage During Cycle Execution (during wash
phase)
[s] 0 182 (*) 8
Rinse Aid Dosage During Cycle Execution (when refill-
ing boiler)
[s] 0 62 (*) 4
Fig. 17 Enter into User Mode (press for 5 sec)..
Fig. 18 Initial detergent
dosage.
Fig. 19 Change duration.
(Tank LED indicates default).
Fig. 20 Initial rinse aid
dosage
Fig. 21 Change duration
Fig. 22 Cycle detergent
dosage.
Fig. 23 Change time
activation (Tank LED
indicates default)
Fig. 24 Cycle rinse aid
dosage.
Fig. 25 Change time
activation.
Val.Fabbr.
Val.Fabbr.
