Emerson Copeland Scroll Digital ZPD34 User Manual

15
© 2015 Emerson Climate Technologies, Inc. All rights reserved.
AE4-1395 R5
Figure 5
Discharge Thermistors
Figure 4
Compressor Capacity Graph
*.ppt 3/23/2010 3:14 PM 1
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
012345678910 11 12 13 14 15
Compressor Capacity (Percent of Full Load)
15 Second Operating Cycle
Solenoid On-Time (Seconds)

Emerson Copeland Scroll Digital ZPD34 Specifications
