16
© 2015 Emerson Climate Technologies, Inc. All rights reserved.
AE4-1395 R5
Figure 6
Modulation Valve Piping
ZPD34-ZPD54K5, ZPD61-ZPD83KC, ZPD91KC, ZPD104KCE, ZPD122KCE, and ZRD36-81KC
Figure 7
Tandem ZPD34-ZPD54K5, ZPD61-ZPD83KC, ZPD91KC, ZPD104KCE, ZPD122KCE, and ZRD36-81KC
Arrow on valve
Must point to suction
Oil Equalization
Line
Suction Gas
Equalization
Manifold
Discharge Manifold
A
ssembly
Suction
Manifold
Assembly
Solenoid Valve
