AE4-1395 R5
Table 4 – Compressor Accessories
The contents of this publication are presented for informational purposes only and they are not to be construed as warranties or guarantees, express or implied, regarding the products or
servicesdescribedhereinortheiruseorapplicability.EmersonClimateTechnologies,Inc.reservestherighttomodifythedesignsorspecicationsofsuchproductsatanytimewithout
notice. Emerson Climate Technologies, Inc. does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of
any Emerson Climate Technologies, Inc. product remains solely with the purchaser and end-user.
Part
Category
Part Description Part Number Models Notes
Modulation
Copeland Scroll
™
Digital
Compressor Controller
943-0024-01 All
15 Second Modulation
Cycle, 24V
Emerson Commercial Comfort
Controller
943-0175-00 All
15 Second Modulation
Cycle, 24V
Modulation Valve & 24V Coil 998-0061-19 ZPD34-54K5
ZPD61-83KC
ZPD91KC
ZPD104KC
ZPD122KC
ZRD34-81KC
All coils have 1/4" spade
electrical terminals
Modulation Valve & 110V Coil TBD
Modulation Valve & 220V Coil 998-0061-17
Modulation Valve, 24V Coil,
Tubing Kit
998-0090-02
ZPD34-54K5
ZPD61-ZPD83
ZPD91KC
ZRD34-81KC
Tubing kit is for 7/8"
compressor suction;
All coils have 1/4" spade
electrical terminals
Modulation Valve & Tubing Kit 998-0090-01
Modulation Valve 910-0182-00
ZPD103
ZPD120
ZPD137-182KC
ZRD94-125KC
All coils have 1/4" spade
electrical terminals
24V Coil: Holding VA (Max)
@ 60 HZ = 20.0
998-0060-03
120V Coil: Holding VA (Max)
@ 60 HZ = 17.3
998-0060-04
200/220V Coil: Holding VA (Max)
@ 60 HZ = 19.2
998-0060-09
Mounting
Refer to the application engineering bulletins for the equivalent non-digital compressor model for
parts in these categories. Or, refer to the 'service parts' section at EmersonClimate.com
Crankcase
Heaters
Oil
Electrical
Tandems
Diagnostics
& Protection
Discharge Line Thermistor
985-0199-00
ZPD34-54K5
ZPD61-83KC
ZRD36-72KC
Fits 1/2" discharge tube
985-0200-00
ZPD103-182KC
ZRD94-125KC
Fits 7/8" discharge tube
985-0262-00
ZPD91KC
ZRD81KC
Fits 3/4" discharge tube
RetrotKits
Commercial Comfort Controller,
Modulation Valve, 24V Coil, &
Tubing Kit
980-7000-00
ZPD34-54K5
ZPD61-ZPD83,
ZPD91, ZPD104
ZPD122KC
ZRD36-48KC
ZRD61-81KC
Thermistor 085-0204-00
and clamp 032-0689-00
must be used with
ZRD81KC and ZPD91KC
applications
Commercial Comfort Controller,
Discharge Thermistor, & 24V Coil
980-7000-01
ZPD103, ZPD120,
ZPD137-182KC
ZRD94-125KC
Flow Washer
14.40 I.D. & 22.13 O.D. 102-0164-11 ZPDU-85K
See tandem drawings for
owwasherlocation.
13.50 I.D. & 22.13 O.D. 102-0164-12 ZPDU-10M
