Instruction Manual
D104239X012
Multiport Flow Selector
January 2019
10
Table 6. Bonnet Bolting Torque
VALVE SIZE,
NPS
ASME
CLASS RATING
STUD SIZE TORQUE
mm Inch Nm ftlbf
2 x 4
300
600
900
25.4 1 217 160
3 x 6
150
300
600
900
31.8 1-1/4 441 325
1500 38.1 1-1/2 814 600
4 x 8
300
600
900
34.9 1-3/8 651 480
4 x 10 1500 44.5 1-3/4 1356 1000
6 x 16
300
600
41.3 1-5/8 1085 800
900 50.8 2 2034 1500
1500 63.5 2-1/2 4203 3100
2500 82.6 3-1/4 10170 7500
Plug Seal Adjustment
1. Prior to adjusting the seal assembly (key 12 and 13), align the plug (key 2) with an open inlet port and insert the
supplied adjustment tool. Once this tool has been secured to the seal adjuster (key 18), rotate this tool counter
clockwise until the scraper (key 10) touches the inside surface of the body (key 1). The resistance to rotate the
adjustment tool will increase once the scraper contacts the body. Remove the adjustment tool.
2. Rotate the plug (key 2) a few revolutions to check for binding or excessive turning torque. If the plug rotates
smoothly, then insert, secure, and rotate the adjustment tool counter clockwise to tighten the seal adjuster (key
18) to the appropriate torque value listed in table 7.
Note
Do not exceed the torque values listed in table 7. Exceeding these values may cause the valve to not function as intended.
Table 7. Plug Seal Torque
VALVE SIZE, NPS ASME CLASS RATING
TORQUE
Nm ftlbs
2 x 4
300
600
900
41 30
3 x 6
150
300
600
48 35
900
1500
41 30
4 x 8
300
600
900
54 40
4 x 10 1500 54 40
6 x 16
300
600
900
1500
2500
95 70
