Emerson Fisher Multiport Flow Selector User Manual

Instruction Manual
D104239X012
Multiport Flow Selector
January 2019
3
Specifications
The Multiport Flow Selector specifications are given in tables 1 through 5.
Table 1. Valve Specifications NPS 2x4 and 3x6
SPECIFICATIONS
VALVE SIZE
2 x 4 3 x 6
ASME Class Rating
(1)
CL300 CL600 CL900 CL150 CL300 CL600 CL900 CL1500
Weight, kg (lb) 91 (200) 91 (200) 363 (800) 553 (1220) 630 (1390) 658 (1450) 680 (1500) 968 (2135)
Inlet Ports NPS 2 NPS 3
Test Outlet Port NPS 2 NPS 3
Group Outlet Port NPS 4 NPS 6
End Connections Mates with raised-faced flanges per ASME B16.5
Temperature Range
(2)
-1 to 204°C (30 to 400°F)
Shutoff ANSI/FCI 70-2 Class IV
1. The pressure/temperature limits in this instruction manual and any applicable standard or code limitation should not be exceeded.
2. Standard O-ring material established upper and lower temperature limits.
Table 2. Valve Specifications NPS 4x8, 4x10, and 6x16
SPECIFICATIONS
VALVE SIZE
4 x 8 4x10 6 x 16
ASME Class Rating CL300 CL600 CL900 CL1500 CL300 CL600 CL900 CL1500 CL2500
Weight, kg (lb)
959
(2115)
975
(2150)
1134
(2500)
1742
(3840)
1810
(3990)
2018
(4450)
3590
(7915)
5343
(11780)
8704
(19190)
Inlet Ports NPS 4 NPS 4 NPS 6
Test Outlet Port NPS 4 NPS 4 NPS 6
Group Outlet Port NPS 8 NPS 10 NPS 16
End Connections Mates with raised-face flanges per ASME B16.5
SPO
Compact
Flange
Temperature Range
(1)
-1 to 204°C (30 to 400°F)
Shutoff ANSI/FCI 70-2 Class IV
1. The pressure/temperature limits in this instruction manual and any applicable standard or code limitation should not be exceeded.
2. Standard O-ring material established upper and lower temperature limits.
Table 3. Actuator Specifications
SPECIFICATIONS
VALVE SIZE AND ASME CLASS RATING
NPS 2 x 4
CL300/600/900
NPS 3 x 6
CL150/300/
600/900/1500
NPS 4 x 8
CL300/600/900
NPS 4 x 10
CL1500
NPS 6 x 16
CL300/
600/900/
1500/2500
Max Torque Output,
Nm (ftlbf)
203 (150) 881 (650) 1085 (800) 1085 (800) 2034 (1500)
Actuator Speed, RPM 1.0 0.5-1.0 0.5-1.0 0.5-1.0 0.3-0.5
Actuator Weight, kg (lb) 82 (180)
Plug Position Accuracy ± 1°
