58 FXMP25 User Guide
www.controltechniques.com Issue Number: 3
8.17 Electromagnetic compatibility (EMC)
This is a summary of the EMC performance of the FXMP25. For full details, refer to the
FXMP25 EMC data sheet which can be obtained from the supplier of the FXMP25.
Table 8-5 Immunity compliance
1
See section 4.6.1 Surge immunity of control circuits - long cables and connections
outside a building on page 22 for control ports for possible requirements regarding
grounding and external surge protection.
Standard
Type of
immunity
Test specification Application Level
EN 61000-4-2
IEC 61000-4-2
Electrostatic
discharge
6 kV contact discharge
8 kV air discharge
Module
enclosure
Level 3
(industrial)
EN 61000-4-3
IEC 61000-4-3
Radio
frequency
radiated field
80 % AM (1 kHz) modulation
Levels prior to modulation:
10V/m 80 - 1000 MHz
3V/m 1.4 – 2.0 GHz
1V/m 2.0 – 2.7 GHz
Module
enclosure
Level 3
(industrial)
EN 61000-4-4
IEC 61000-4-4
Fast transient
burst
5/50ns 2 kV transient at 5 kHz
repetition frequency via coupling
clamp
Control lines
Level 4
(industrial
harsh)
5/50ns 2 kV transient at 5 kHz
repetition frequency by direct injection
Power lines
Level 3
(industrial)
EN 61000-4-5
IEC 61000-4-5
Surges
Common mode 4 kV
1.2/50 μs waveshape
AC supply lines:
line to ground
Level 4
Differential mode 2 kV
AC supply lines:
line to line
Level 3
Common mode 1 kV
Control lines
1
EN 61000-4-6
IEC 61000-4-6
Conducted
radio
frequency
10 V prior to modulation
0.15 - 80 MHz
80 % AM (1 kHz) modulation
Control and
power lines
Level 3
(industrial)
EN 61000-4-11
IEC 61000-4-11
Voltage dips,
short
interruptions
& variations
All durations AC supply lines
EN 61000-4-8
IEC 61000-4-8
Power
frequency
magnetic
field
Exceeds level 5
Module
enclosure
Level X
(1mT)
EN 61000-6-
1:2007
IEC 61000-6-1
Generic immunity standard for the residential,
commercial and light - industrial environment
Complies
EN 61000-6-
2:2005
IEC 61000-6-2
Generic immunity standard for the industrial
environment
Complies
EN 61800-
3:2004
IEC 61800-3
Product standard for adjustable speed power drive
systems (immunity requirements)
Meets immunity requirements for
first and second environments
