Emerson XR75CX User Manual

MODBUS Termination Blocks Default Setting Values • 27
19 Default Setting Values
Label Name Range Value Level
SEt Setpoint LS to US -5.0 ---
rtc* Real time clock menu - - Pr1
Hy Differential 0.1 to 25.5°C/ 1 to 255°F 2.0 Pr1
LS Minimum setpoint -100°C to SEt/-58°F to SEt -50.0 Pr2
US Maximum setpoint SEt to 110°C/ SEt to 230°F 110 Pr2
ot Thermostat probe calibration -12 to 12°C /-120 to 120°F 0.0 Pr1
P2P Evaporator probe presence n = not present; Y = present Y Pr1
oE Evaporator probe calibration -12 to 12°C /-120 to 120°F 0.0 Pr2
P3P Third probe presence n = not present; Y = present n Pr2
o3 Third probe calibration -12 to 12°C /-120 to 120°F 0 Pr2
P4P Fourth probe presence n = not present; Y = present n Pr2
o4 Fourth probe calibration -12 to 12°C /-120 to 120°F 0 Pr2
Ods Outputs delay at start up 0 to 255 min 0 Pr2
Ac Anti-short cycle delay 0 to 50 min 1 Pr1
rtr P1-P2 percentage for regulation 0 to 100 (100 = P1, 0 = P2) 100 Pr2
CCt Continuous cycle duration 0.0 to 24.0 hr 0.0 Pr2
CCS Setpoint for continuous cycle (-100 to 150.0°C) (-67 to 302°F) -5 Pr2
Con Compressor ON time with faulty probe 0 to 255 min 15 Pr2
CoF Compressor OFF time with faulty probe 0 to 255 min 30 Pr2
CF Temperature measurement unit °C to °F °C Pr2
rES Resolution in = integer; dE = decimal point dE Pr1
Lod Probe displayed P1; P2 P1 Pr2
Red
2
X-REP display P1 – P2 – P3 – P4 – SEt – dtr
P1 Pr2
dLy Display temperature delay 0 to 20.0 min (10 sec) 0.0 Pr2
dtr P1-P2 percentage for display 1 to 99 50 Pr2
EdF* Kind of interval for defrost rtC to in rtC Pr2
tdF Defrost type EL = electric heater; in = hot gas EL Pr1
dFP Probe selection for defrost termination nP; P1; P2; P3; P4 P2 Pr2
dtE Defrost termination temperature -50 to 50°C 8 Pr1
IdF Interval between defrost cycles 1 to 120 hr 6 Pr1
MdF (Maximum) length for defrost 0 to 255 min 30 Pr1
dSd Start defrost delay 0 to 99 min 0 Pr2
dFd Displaying during defrost rt, it, SEt, dEF it Pr2
dAd MAX display delay after defrost 0 to 255 min 30 Pr2
Fdt Draining time 0 to 120 min 0 Pr2
dPo First defrost after start-up n = after IdF; y = immediately n Pr2
dAF Defrost delay after fast freezing 0 to 23 hr and 50’ 0.0 Pr2
Table 19-1 - Default Setting Values (
*
Only for models with real time clock (RTC),
2
Only for XR75CX with X-REP output)
