Epiroc MB Series User Manual

Safety and operating instructions
60 © Construction Tools GmbH | 3390 5201 01 | 2023-05-15
Original Instructions
12.2 MB 1200 E, MB 1500 E, MB1650 E
MB1200E MB1500E MB1650E
Carrier weight class
1)
15 - 26 t
(33100 - 57300lbs)
17 - 29 t
(37500 - 63900lbs)
19 - 32 t
(41900 - 70500lbs)
Service weight
2)
1200 kg (2650 lbs) 1500 kg (3300 lbs) 1650 kg (3650 lbs)
Delivery weight
4)
890 kg (1962 lbs) 1078 kg (2377 lbs) 1200 kg (2646 lbs)
Oil flow rate 100 - 140 l/min
(26.4 - 37.0gal/min )
120 - 155 l/min
(31.7 - 40.9gal/min )
130 - 170 l/min
(34.3 - 44.9gal/min )
Operating pressure 160 - 180 bar
(2320 - 2610psi)
160 - 180 bar
(2320 - 2610psi)
160 - 180 bar
(2320 - 2610psi)
Impact rate AutoControl
340 - 680 blows/min
AutoControl
330 - 680 blows/min
AutoControl
320 - 640 blows/min
Working tool diameter 120mm (4.72in.) 135mm (5.31in.) 140mm (5.51in.)
Working length of working tool 600mm (24in.) 635mm (25in.) 670mm (26in.)
Max. hydraulic input power 42 kW (56hp) 46 kW (62hp) 51 kW (68hp)
Back pressure acceptance
8)
30 bar (435psi) 30 bar (435psi) 30 bar (435psi)
Air pressure (min. gauge pressure in percus-
sion chamber)
5)
1.5 bar (22psi) 1.5 bar (22psi) 1.5 bar (22psi)
Air flow (up to depth of 10 meters)
6)
3 m
3
/min (106 ft
3
/min)
Max static pressure (pressure relief valve on
carrier)
200 bar
(2900 psi)
200 bar
(2900 psi)
200 bar
(2900 psi)
Piston accumulator gas pressure (min, at op-
erating temperature 60-70°C)
7)
11.0 bar
(160 psi)
9.8 bar
(142 psi)
10.6 bar
(154 psi)
Piston accumulator gas pressure (max (opti-
mum), at operating temperature 60-70°C)
7)
14.1 bar
(205 psi)
11.8 bar
(171 psi)
12.6 bar
(183 psi)
Hose inside diameter »P« 25 mm (1 in.) 25 mm (1 in.) 25 mm (1 in.)
Hose inside diameter »T« 25 mm (1 in.) 25 mm (1 in.) 25 mm (1 in.)
Start up mode StartSelect StartSelect StartSelect
1)
Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrier manufacturer
prior to attachment
2)
Hydraulic breaker incl. breaker box, working tool and adapter plate of medium size. Please note that the service
weight can be considerably higher, depending on the adapter plate.
4)
Hydraulic breaker, breaker box and ContiLube
®
II without working tool and adapter plate
5)
Air pressure at pressure regulator has to be adjusted to 1.5bar (22psi) plus 0.1bar per meter depth (0.5psi per ft
depth)
6)
Air flow for depth of more than 10meters (33ft): Flow = 0.1 x depth[m] x flow up to 10meters [m
3
/min] (0.0305 x
depth[ft] x flow up to 33ft[cfm])
7)
Hydraulic breaker in horizontal position, no pressure applied to working tool
8)
Back pressure acceptance when breaker still runs regular but at significant reduced performance (oil flow)
