Epiroc SBU 220 User Manual

Safety and operating instructions
© Construction Tools PC AB | 9800 0908 01 | 2023-05-12
Original Instructions
25
11 Technical data
11.1 Machine data
SBU 160 SBU 220 SBU 340
Service weight, kg (lb) 160 (360) 225 (494) 330 (725)
Delivery weight, kg (lb) 132 (290) 177 (390) 248 (547)
Suitable carrier weight class, t (lbs) 2.2-5.0
(4,850-11,023)
2.8-6.0
(6,170-13,225)
4.5-9.0
(9,900-19,840)
Working length of working tool in standard version, mm (in.) 280 (11.0) 330 (13.0) 400 (15.7)
Working tool diameter, mm (in.) 50 (1.97) 65 (2.56) 80 (3.15)
Start up mode AutoStart AutoStart AutoStart
Hose inside diameter P, mm (in.) 12 (½) 19 (¾) 19 (¾)
Hose inside diameter T, mm (in.) 12 (½) 19 (¾) 19 (¾)
11.2 Capacities
SBU 160 SBU 220 SBU 340
Oil flow, l/min (gpm) 30-50 (8-13) 42-75 (11-20) 62-100 (16-26)
Impact rate, bpm 1000-2000 750-1400 700-1300
Operating pressure, bar (psi) 100-150
(1450-2175)
100-150
(1450-2175)
100-150
(1450-2175)
Maximum hydraulic input power, kW (hp) 13 (17.4) 19 (25.5) 25 (33.5)
Back pressure acceptance, bar (psi) 8 (116) 35 (508) 35 (508)
Accumulator gas pressure, bar (psi) 40 (580) 40 (580) 40 (580)
Pressure relief valve on breaker, bar (psi) 180 (2611) 180 (2611) 185 (2683)
Water pressure, bar (psi) 4 (58) 4 (58) 4 (58)
Water consumption, l/min (gpm) ≤5 (≤1.3) ≤5 (≤1.3) ≤9 (≤2.4)
Air pressure, bar (psi) 2 (29) 2 (29) 2 (29)
Air flow, m
3
/min (ft
3
/min) ≤0.73 (≤26) ≤0.73 (≤26) ≤0.73 (≤26)
