Epson EX21 User Manual

Setting Up the Projector 19
Connecting to the USB Port
You can connect a Windows Vista, XP, or Windows 2000 (SP4)
computer to the projector’s
TypeB (square) USB port and
project your computer’s display. A USB 2.0 connection
(recommended) provides better picture quality and response than
USB 1.1.
The first time you connect a computer to the projector’s USB port,
software from the projector is installed on your computer.
1. Follow the instructions beginning on page 26 to turn on the
projector.
2. Make sure the
USB Type B setting on the Extended menu is set
to
USB Display (see page 50).
3. Turn on your computer.
4. Connect the square end of a USB cable to the projector’s
TypeB
(square) USB port.
5. Connect the flat end of the cable to any available USB port on
your notebook or desktop computer.
Messages appear on your computer screen as the projector is
recognized and the software is installed automatically.
6. Follow the instructions on the screen to install the Epson USB
Display software. If you see a “Digital Signature Warning,” select
Continue or Continue Anyway. (You will see these instructions
only the first time you connect.)
USB TypeB port

Epson EX21 Specifications

Projection

projection system	Epson 3LCD, 3-chip technology
white light output	2200 lumens
color light output	2200 lumens
aspect ratio	4:3
native resolution	800 x 600 (SVGA)
resize resolution	640 x 480 (VGA)
contrast ratio	2000:1

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	246 W, 3 W standby
lamp type	170 W UHE

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
lamp life in ECO mode	Up to 4000 hours
lamp life in normal mode	Up to 3000 hours
fan noise in normal mode	35 dB
fan noise in ECO mode	28 dB

Lens

lens type	Digital zoom/Manual focus
f-number	1.44
focal length	16.6 mm
zoom ratio	Digital zoom 1.0 – 1.35

Weight and Dimensions

dimensions including feet	12.9" x 9.6" x 4.0"
dimensions excluding feet	12.9" x 9.6" x 3.6"
weight	6.0 lb
