81
A
Projector Installation
This appendix provides guidelines on installing the projector in a
permanent location, such as a theater or conference room.
The projector can be installed for four different viewing setups: front
projection, ceiling projection, rear projection onto a semi-transparent
screen, or rear/ceiling projection, as shown:
To project from overhead, you’ll need the optional ceiling mounting
hardware; see page 11 for ordering information. You’ll also need to
select
Front/Ceiling or Rear/Ceiling as the Projection option in the
projector’s Extended menu to flip the image upside-down. To project
from the rear, onto a semi-transparent screen, select
Rear or
Rear/Ceiling (see page 57).
Front projection Rear projection
Rear/ceiling projectionCeiling projection
