Notes on Usage and
Storage
Installation space
Make sure that you secure the following space, clear of
any other objects, so that paper ejection and
consumable replacement are not obstructed.
See the “Specifications Table” for the external
dimensions of the printer.
U “Specifications Table” on page 235
SC-T5400 Series/SC-T5400M Series/SC-T3400 Series
W D H
SC-T5400
Series/
SC-T5400M
Series
1535 mm 1350 mm 1220 mm
SC-T3400
Series
1230 mm 1350 mm 1220 mm
SC-T3400N Series/SC-T5400 Series/SC-T5400M
Series/SC-T3400 Series
SC-T5400 Series/SC-T5400M Series/SC-T3400 Series
without the stand.
W D H
SC-T5400M
Series/
SC-T5400
Series
1535 mm 1288 mm 735 mm
SC-T3400N
Series/
SC-T3400
Series
1230 mm 1288 mm 760 mm
Notes when using the printer
Note the following points when using this printer to
avoid breakdowns, malfunctions, and print quality
decline.
❏ When using the printer, observe the operating
temperature and humidity range described in the
"Specifications Table".
U “Specifications Table” on page 235
Even when the conditions above are met, you may
not be able to print properly if the environmental
conditions are not suitable for the paper. Be sure to
use the printer in an environment where the paper's
requirements are met. For more details, see the
documentation supplied with the paper.
Also, when operating in dry areas, air conditioned
environment, or under direct sunlight, maintain
the appropriate humidity.
❏ Do not install the printer next to heat sources or
directly in the path of air from a ventilator or air
conditioner. Failure to observe this precaution
could result in the print head nozzles drying and
clogging.
SC-T5400 Series/SC-T5400M Series/SC-T3400 Series/SC-T3400N Series User's Guide
Introduction
21
