Requirements and Specifications
48
Specifications
Printer specifications
Printing
Printing method On-demand ink jet
Nozzle configuration Black 48 nozzles
Color 45 nozzles (15 each: cyan, magenta, yellow)
Print direction Bidirectional with logic seeking
Print speed 12 ppm
Input buffer 12KB
Mechanical
Paper feed method Friction
Paper path Sheet feeder, top entry
Sheet feeder capacity 100 sheets of 65.8 g/m
2
(17 lb) paper
Dimensions Storage Width: 42.4 cm (16.7 in)
Depth: 22.9 cm (9.0 in)
Height: 17.2 cm (6.8 in)
Printing Width: 42.4 cm (16.7 in)
Depth: 46.0 cm (18.1 in)
Height: 27.7 cm (10.9 in)
Weight 2.48 kg (5.47 lb) without the ink cartridges
Electrical
Rated voltage (Universal Power
Supply)
AC 100 - 240 V
Input voltage range* 90 to 264 V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 0.4 - 0.2 A
Power consumption Approx. 19 W (ISO10561 Letter Pattern)
Approx. 3.0 W Sleep mode
Approx. 2.7 W Power Off Mode
