<Function 4> GS ( C pL pH m fn b (fn = 4, 52)
[Format] ASCII GS ( C pL pH m fn b
Hex 1D 28 43 pL pH m fn b
Decimal 29 40 67 pL pH m fn b
[Range] (p
L + pH × 256) = 3 (pL = 3, pH = 0)
m = 0
fn = 4, 52
b = 0
[Description] • Transmits the number of bytes of the remaining memory (unused area) in the NV user
memory.
<Function 5> GS ( C pL pH m fn b (fn = 5, 53)
[Format] ASCII GS ( C pL pH m fn b
Hex 1D 28 43 p
L pH m fn b
Decimal 29 40 67 pL pH m fn b
[Range] (p
L + pH × 256) = 3 (pL = 3, pH = 0)
m = 0
fn = 5, 53
b = 0
[Description] • Transmits the list of the key code of the record in the NV user memory.
<Function 6> GS ( C pL pH m fn b d1 d2 d3 (fn = 6, 54)
[Range] ASCII GS ( C pL pH m fn b d1 d2 d3
Hex 1D 28 43 pL pH m fn b d1 d2 d3
Decimal 29 40 67 pL pH m fn b d1 d2 d3
[Range] (p
L + pH × 256) = 6 (pL = 6, pH = 0)
m = 0
fn = 6, 54
b = 0
d1 = 67
d2 = 76
d3 = 82
[Description] • Deletes all data in the NV user memory.
