5.3. Mapping the Touchscreens
About the Mapping Process
The touchscreens are automatically mapped. The mapping process is necessary to make
sure that the touch gestures performed by the user on one particular half of the monitors,
e.g. selecting an element, actually take effect on that half, and not on the same half of the
other monitor.
If the touchscreen monitors are not mapped and the user selects an element on the left
half of the secondary screen, an element on the left half of the primary screen will be
selected instead. If the user selects an element on the right half of the primary screen, an
element on the right half of the secondary screen will be selected instead.
Touchscreen Mapper
The Touchscreen Mapper application is the tool that performs the mapping for you.
It is automatically launched each time you start the X-One client. It also has a shortcut on
the server desktop to manually start the application.
When to Start the Mapping Process
The mapping process has to be started each time:
• one of your monitors is unplugged and plugged in again;
• the order of the screens is changed;
• an X-One server (PMX) is rebooted.
How to Start the Mapping Process
To start the mapping of your touchscreens, proceed as follows:
1. Double-click the X-One client shortcut.
The TouchScreen Mapper application is automatically launched.
You are prompted to tap your main screen.
16 5. Configuration
EVS Broadcast Equipment SA 1.7.0.D- January 2021
