s
+
24Vac
IN
1 2
3
4
5 6
7
2
1
3
GND
*
(+) (-)
GND
IN
GND
24
GND
+ s -
white
brown
green
yellow
blue
red
black
Vortex damper
control
Direction Sensitive
RPM feedback
- DSR (ATM only)
Cable 7×0.14mm2
shielded
AT motor
Position feedback
Wiring connection
Alignment lock
Trimming
potentiometer
max. stroke
Connection box
Cable entry:
ATM 7×0.8mm
AT 4×0.8mm
Terminal strip
2.3 Install the protective screen (optional)
Turn the power supply off before cleaning or before carrying out any maintenance.
Before mounting the protective screen, make sure that the impeller is not turning.
6
