FLIR CX series User Manual

Operation
7
7.1 Charging the battery
Follow this procedure:
1. Connect the FLIR power supply to a wall outlet.
2. Connect the power supply cable to the USB connector on the camera.
7.2 Turning on and turning off the camera
• Push the On/off button
to turn on the camera.
• Push and hold the On/off button
until the screen goes off (for less than 5 sec-
onds) to put the camera in standby mode. The camera then automatically turns off
after 2 hours.
• Push and hold the On/off button
for more than 5 seconds to turn off the
camera.
7.3 Saving an image
7.3.1 General
You can save images to the internal camera memory.
The camera saves both a thermal image and a visual image at the same time.
7.3.2 Image capacity
Approximately 500 images can be saved to the internal camera memory.
7.3.3 Naming convention
The naming convention for images is FLIRxxxx.jpg, where xxxx is a unique counter.
7.3.4 Procedure
Follow this procedure:
1. To save an image, push the Save button.
7.4 Recalling an image
7.4.1 General
When you save an image, it is stored in the internal camera memory. To display the im-
age again, you can recall it from the internal camera memory.
7.4.2 Procedure
Follow this procedure:
1. Tap the camera screen. This displays the main menu toolbar.
2. Select Images
. This displays an image in the image archive.
3. To view the previous or next image, do one of the following:
• Swipe left or right.
• Tap the left arrow
or the right arrow .
4. To switch between a thermal image and a visual image, swipe up or down.
#T559918; r. AE/23547/23547; en-US
13
