FLIR K Series User Manual

In-truck charger (optional accessory)
12
12.7 Charging a battery separately
Flir K series batteries can be charged separately using the battery charger at the lower
front of the unit.
Follow this procedure:
1. Pull the eccentric latch on the bottom of the camera.
2. Pull out the battery from the camera.
3. Push the battery into the slot at the lower front of the charger.
4. Secure the battery using the eccentric latch on the charger.
The charging of the battery has now started, and is finished when the blue light glows
continuously. Charging a fully depleted battery takes approximately 4 hours.
12.8 Technical data
Dimensions (height × width × depth) 380 mm × 180 mm × 153 mm (15″ × 7.1″ × 6″)
Weight 2.2 kg (4.8 lb)
Power input
12–24 VDC
Charging time (camera) ≈ 4 hours
Charging time (separate battery)
≈ 4 hours
Maximum current 3 A
Nominal current 2.3 A
12.9 Cleaning
CAUTION
Disconnect the in-truck charger from the fire engine’s 12–24 VDC system before cleaning.
The in-truck charger can be cleaned using warm water or a weak detergent solution. Do
not use solvents or similar liquids.
12.10 Customer support
Should you experience any problems, do not hesitate to contact our Customer Support
at http://support.flir.com.
#T559811; r. AE/ 9082/9150; en-US
25
