DCO65U-E SC2500 User Manual Page 33
10. Technical data
10.1. Characteristics
Detector Materials
InGaAs (SC2500N)VisGaAs (SC2500VN)
Spectral Response
0.9-1.7µm (SC2500N)
0.4-1.7 µm (SC2500VN)
Number or Pixels
320x256
Pitch
30µm
Sub Windowing
Down to 128x8 (User defined)
Frame Rate
1 Hz to 340Hz Full Frame
11KHz at 128x8 sub window
Frame rate resolution
0.1 Hz step
Image Capture Mode
Snapshot
Image Capture Readout Modes
Integrate then Read mode (ITR)
Integrate While Read (IWR)
Short Integrate then Read (Fast ITR)
Detector Temperature Stabilization
TEC (can be deactivated)
Stabilization Time
<1 min @ 25°C ambient
Camera External Trigger
LVTTL 0 – 3.3V
Lockin Input
0 – 10 Vpp, 1 Hz up to 5 kHz
Integration Time
400ns to 1s, 200ns step
Detector Gain
Low gain : x1 High gain : x20
Well capacity
Low gain : 3.5Me- High Gain : 0.17Me-
NEI
Low gain : <5 10
9
ph/s/cm²
High gain : <3 10
10
ph/s/cm²
Noise
<150e- RMS (typical)
Quantum efficiency
>70% @ 1.5µm
Power Supply
12VDC
Power consumption
< 15W
Digital Video
Gigabit Ethernet
Analog Video
PAL (50 Hz) or NTSC (60 Hz)
Remote Control
Gigabit Ethernet
Overall dim, (mm)
172x82x50
Weight (W/O lens)
900g
Water & humidity
IP54
Operational temperature range
0-50°C non condensing
