Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
40 — Not used
41 G8VA relay Backup lamps
42 — Not used
43 G8VA relay A/C clutch
44 — Not used
45 15A** Injectors
46 15A** PCM
47 10A** General powertrain components,
A/C clutch relay, Backup lamps
48 15A** Ignition coils
49
15A** Emissions related powertrain
components (2.5L & 3.5L)
20A** Emissions related powertrain
components (3.0L)
50 — Not used
51 — Not used
52 Full ISO relay Blower motor relay
53 Full ISO relay Rear defrost relay
54 Full ISO relay Fuel relay
55 Full ISO relay Starter relay
56 — Not used
57 Full ISO relay PCM relay
58 — Not used
* Cartridge Fuses ** Mini Fuses
CHANGING THE TIRES
If you get a flat tire while driving, do not apply the brake heavily.
Instead, gradually decrease your speed. Hold the steering wheel firmly
and slowly move to a safe place on the side of the road.
Note: The tire pressure monitoring system (TPMS) indicator light will
illuminate when the spare tire is in use. To restore the full functionality
of the monitoring system, all road wheels equipped with tire pressure
monitoring sensors must be mounted on the vehicle.
