Replacing front parking lamp/turn signal bulbs (2.5L/3.0L engines)
1. Make sure headlamp control is in the off position, then open the hood.
2. Reach over the front bolster.
3. Disengage the windshield washer bottle flexible neck strap attachment
and move it to gain access to the bulb.
4. Remove the bulb socket by
rotating it counterclockwise, then
pull it out of the lamp assembly.
5. Carefully pull bulb straight out of
socket and push in the new one.
6. Install new bulb socket into the
lamp assembly by aligning the
indexing fingers, then rotate
clockwise to locked position.
Lights
68
2010 Fusion (fsn)
Owners Guide, 2nd Printing
USA (fus)
