For passenger side replacement of the front park/turn signal bulb, do
the following:
1. Turn the steering wheel left to gain access to the wheel well.
2. Remove the press pins located in
the wheel well and pull the splash
shield back.
3. Remove the bulb socket by rotating it counterclockwise, then pull it
straight out of the lamp assembly.
Replace with a new bulb, and reverse the removal steps to complete the
process.
Replacing front side marker bulbs
1. Make sure the headlamp control
is in the off position.
2. From underneath the vehicle,
partially remove the tire splash
shield by removing the press pins.
After removing to allow free access
to the front side marker lamp bulb
and electrical wire harness, the
splash shield should be able to be
repositioned.
3. Rotate the lamp clockwise while holding the electrical connector in
place. After rotating the lamp 90 degrees clockwise, pull and disengage
the wire harness and bulb from the lamp.
Lights
70
2010 Fusion (fsn)
Owners Guide, 2nd Printing
USA (fus)
