Low fluid level
Type A
Type B
Do not drive the vehicle if the fluid level is at the bottom of the dipstick
and the outside temperatures are above 50°F (10°C).
Correct fluid level
The transmission fluid should be checked at normal operating
temperatures 185°F-200°F (85°C-93°C) on a level surface. The normal
operating temperature can be reached after approximately 20 miles
(30 km) of driving.
Type A
Type B
The transmission fluid should be in the zone, identified by the arrows in
the above figures, if at normal operating temperature 185°F-200°F
(85°C-93°C).
DO NOT ADD
ADD (CHECK HOT)
DO NOT ADD
ADD (CHECK HOT)
Maintenance and Specifications
318
2010 Fusion (fsn)
Owners Guide, 2nd Printing
USA (fus)
