Before You Begin6
Kensington Lock
The AP832e has an access slot at the back to support Kensington Lock. Users can lock the
AP832e with a standard security cable, such as those used to secure laptop computers. See
“AP832 Kensington lock” on page 6 for location of AP832 Kensington Lock.
Figure 1: AP832 Kensington lock
Power Options
A power source is needed to power the AP832e. The AP832e requires either IEEE Std
802.3af or IEEE Std 802.3at compatible external Power-over-Ethernet (PoE) switch or PoE
injector. If the PoE power source is not available, a 12-V DC power (2A rated) must be sup-
plied.
When connected to an IEEE Std 802.3af PoE power source, both the USB and the secondary Ethernet
port (G2) shall be disabled due to power limitations.
AP832 is intended to be supplied by a UL listed power supply marked Class 2 or LPS and rated 12Vdc,
2A. If an optional power supply is used, it must be one supplied by Fortinet.
