FP4000 Rev0204

Install External Totalizing Button Option

1. Mount a momentary on (SPST) switch near the display.

2. Connect a wire from one terminal of the switch to ground.

3. Connect a wire from the other terminal of the switch to pin 10 on the display

module connector. (Refer to Wiring section.)
