Technical data
Technical data Modbus transmission speed: 9600 baud
Parity bit:none
Software version:
- Fronius Datamanager 2.0 (from version 3.16.1 onwards)
- Fronius Symo Hybrid (from version 1.16.1 onwards)
Measuring input
Nominal voltage (1-phase)
Operating range
230 V (-30% to +20%)
Self-consumption - voltage path (max.
voltage)
≤ 8 VA
Nominal frequency
Tolerance
50 - 60 Hz
45 - 65 Hz
Nominal current, l
b
5 A
Maximum current, I
max
100 A
Starting current 40 mA
Short-time overload
(EN IEC 62053-21, EN IEC 62053-23)
30 l
max
/ 0.001 s
Self-consumption - current path (max. cur-
rent)
≤ 1 W
Power factor
Operating range
(EN IEC 62053-21, EN IEC 62053-23)
cosφ 0.5 ind - 0.8 cap,
Current distortion factor In acc. with EN 62053-21
Data output
RS485 communication
Electrically isolated from measuring input
Standard RS485 - 3 conductors
Transmission Serial, asynchronous
Protocol Compatible with Modbus RTU
Addresses 1 - 255
Number of bits 8
Stop bit 1
Parity bit None - odd - even
Baud rate 9600, 19200 bit/s
Response time ≤ 200 ms
Insulation (EN IEC 62052-11, EN IEC 62053-21)
Installation category III
Pollution degree 2
35
EN

Fronius Smart Meter TS Series Specifications
