Suitable Grids
Delta
Setup:
208
240
220
BR
50 Hz
MG 3P
MG 1P
No neutral conductor
Nominal voltage:
208 V
240 V
220 V
220 V
50 Hz 208–240 V
Microgrid 208 V
Microgrid 240 V
Appropriate inverter:
Symo Advanced
10.0-3 208–240 / 12.0-3
208–240
WYE
Setup:
208 N
220 N
BR N
50 HN
HI2
480 N
440 N
50 HN
MG 3N
MG 2N
MG 5N
MG 6
CAL3
HI3
Neutral conductor required
Nominal voltage:
208 V
220 V
220 V
50 Hz 208–240 V
208 V
480 V
440 V
50 Hz 415 V
Microgrid 208 V
Microgrid 50 Hz 208–240 V
Microgrid 50 Hz 480 V
Microgrid 480 V
480 V
480 V
Appropriate inverter:
Symo Advanced
10.0-3 208–240 / 12.0-3
208–240
Symo Advanced
15.0-3 480 / 20.0-3 480 /
22.7-3 480 / 24.0-3 480
Hi-Leg Delta
Setup:
240 N
50 HN
MG 1N
MG 2N
HI1
Neutral conductor required
Nominal voltage:
240 V
50 Hz 208–240 V
Microgrid 240 V
Microgrid 50 Hz 208–240 V
208 V
Appropriate inverter:
Symo Advanced
10.0-3 208–240 / 12.0-3
208–240
=
~
L1
L2
L3
L2-L3
120°
=
~
L1
L2
L3
N
L2-L3
120°
=
~
L3
L1
L2
N
L1-NL2-N
L2-L3
L3-L1
90°
90°
180°
