8-5
8.6 Compliance with Functional Safety Standard
8.6.1 General
In FRENIC-Lift series of inverters, opening the hardware circuit between terminals [EN1]-[PLC] or between
terminals [EN2]-[PLC] stops the output transistor, coasting the motor to a stop (EN: Enable input). This is the
Safe Torque Off (STO) compliant with Functional Safety Standard EN/IEC 61800-5-2.
Using the Safe Torque Off (STO) function eliminates the need of external safety circuit breakers (i.e. magnetic
contactors) while conventional inverters need those breakers to set up the system compliant to Functional
Safety Standard.
Table 8.3 shows the functional safety function performance.
Table 8.3 Functional Safety Function Performance
EN ISO 13849-1
Category 3
Performance level e
DCave >= 90% (medium)
Response time
(Safety reaction time)
<= 50 ms
(Delay time from when either of terminals [EN1]
and [EN2] comes OFF to STO)
MTTFd for each channel >= 30 years
EN 61508-1 to -7
EN 61800-5-2
Safety Function (Stop function) STO (Safe Torque Off)
SIL (Safety integrity level) SIL3 (Type B)
HFT (Hardware Fault Tolerance) 1
SFF (Safe Failure Fraction) >= 90%
PFDave
☓
10
-3
(Average of Probability of Failure on Demand)
PFH
☓
(Probability of a dangerous random hardware
Proof test interval (Lift time) 10 years
• The output shutdown function of this inverter uses the Safe Torque Off (STO) function prescribed in IEC/EN
61800-5-2 so that it does not completely shut off the power supply to the motor electrically. Depending upon
applications, therefore, additional measures are necessary for safety of end-users, e.g., brake function that locks
the machinery and motor terminal protection that prevents possible electrical hazard(s).
• The output shutdown function does not completely shut off the power supply to the motor electrically. Before
starting wiring or maintenance jobs, therefore, be sure to disconnect the input power to the inverter and wait at
least five minutes.
