4. Louver control

4-1. Vertical airflow direction louver control

Each time the button is pressed, the air direction range will change as below:

1 2 3 4 5 6

• Remote controller display is not changed.

• Vertical airflow direction is set automatically as shown, in accordance with the type of operation

selected.

Cooling/dry mode : Horizontal flow 1

Heating mode : Downward flow 7

• During AUTO operation, for the first a few minutes after beginning operation, airflow will be hori-

zontal 1; the air direction cannot be adjusted during this period.

The airflow direction setting will temporarily become 1 when the temperature of the airflow is low at

the start of the Heating mode.

• After beginning of AUTO/HEAT mode operated and automatic defrosting operation, the airflow will

be horizontal 1. However, the airflow direction cannot be adjusted at beginning AUTO operation

mode.

4-2. Swing operation

• To select vertical airflow swing operation

When the swing signal is received, the vertical airflow direction louver starts to swing.

– Swinging range

• Cooling mode/dry mode/fan mode: 1 ↔ 7

• Heating mode: 1 ↔ 7

– When the indoor fan is S-LOW or stop mode, the swing operation is interrupted and it stops at

either upper end or bottom end.

4-1. Vertical airflow direction louver control - (04-14) - 4. Louver control

CONTROL AND

FUNCTIONS

CONTROL AND

FUNCTIONS
