Fujitsu ASYG14LTCB User Manual

-
(
02 - 01
)
-
OUTDOOR UNIT AO

G09-14LT
OUTDOOR UNIT AO

G09-14LT
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AO

G09LTCN AO

G12LTCN AO

G14LTCN
Power sourse 230V ~ 50Hz
Available voltage range 198-264V ~ 50Hz
Starting current A 3.3 4.3 6.1
Fan
Airflow rate
Cooling
m
3
/h
1,700 2,050
Heating 1,700 2,000
Type×Q'ty Propeller fan×1
Motor output W 50 115
Sound pressure level
Cooling
dB(A)
48 50
Heating 49 50
Heat exchanger type
Dimensions(H×W×D)
mm
504 × 896 × 36.4 588 × 881 × 36.4
Fin pitch 1.3 1.3
Rows×Stages 2 × 24 2 × 28
Pipe type Copper
Fin Type Aluminium
Compressor
Type×Q'ty Rotary × 1
Motor output W 850 1,000
Refrigerant
Type R410A
Charge g 1,050 1,200 1,250
Refrigerant oil Type POE(VG74)
Enclosure
Material Steel
Colour
Beige
Approximate colour of MUNSELL 10YR7.5/1.0
Dimensions
(H×W×D)
Net
mm
540 × 790 × 290 620 × 790 × 290
Gross 633 × 945 × 395 713 × 945 × 395
Weight
Net
kg
36 40
Gross 40 43
Connenction pipe
Size
Liquid
mm
Ø6.35 (Ø1/4 in.)
Gas Ø9.52 (Ø3/8 in.) Ø12.70 (Ø1/2 in.)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
10 to 43
Heating -25 to 24
Note :
Specifications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB/24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB/6 °CWB.
Pipe length : 5 m, Height difference : 0 m.(Outdoor unit - Indoor unit)
The maximum current is the maximum value when the operated within the operation range (temperature).
The protective function might work when using it outside the operation range.
