5. CONTROL SYSTEM
PACKING LIST
Name and shape Quantity
Application
Installation manual
1
Operating manual
1
Cover 1 For covering receiver unit
Insulation 1 For protecting PCB from dust
Connection cable A
(5m)
1 For connecting PCB of indoor unit to receiver unit
Connection cable B
(0.2m)
1 For connecting PCB of indoor unit to receiver unit
Bracket (cover)
1 or ing receier unit to the wa or ceiing
Screw
(M3 x 12mm)
2 For installing remote control unit holder to the wall
Screw
(M4 x 20mm)
2 For installing receiver unit to the wall or ceiling
Battery (R03/LR03)
2 For remote controller
Remote controller holder
1 Use as remote controller holder
SPECIFICATIONS
(IR Receiver)
Dimensions [H x W x D]: (mm)
145 x 90 x 30
Weight: (g) 150
OPTIONAL SERVICE PARTS
Please use the parts number shown below to order the cable from your sales representative.
Select shielded type conncetion cable in accordance with the standard of the country.
Name and shape
Parts No.
Connection cable C
(
10m) 9707598025
