6. SYSTEM DESIGN
INDOOR UNIT9-2.
COMPACT CASSETTE TYPE
Name and shape Q'ty Application
Operating
manual
1
Installation
manual
1
Coupler heat
insulation
(Large)
1
For indoor side pipe joint
(Gas pipe)
Coupler heat
insulation
(Small)
1
For indoor side pipe joint
(Liquid pipe)
Special nut A
arge ange
4
For installing indoor unit
Special nut B
a ange
4
For installing indoor unit
Template
(Carton top)
1
For cealing openings
cutting
Also used as packing
Cable tie
2
For electrical wiring
Wire clamper
1
For electrical wiring
Drain hose
1
For installing drain pipe
VP25 (O.D.32, I.D.25)
Hose band
1
For installing drain hose
Drain hose insulation
1
For installing drain pipe
Remote controller
1
Battery
2
Remote controller
holder
1
Tapping screw
(M3 x 12mm)
2
For mounting the remote
controller holder
Name and shape Q'ty Application
Connector cover
1
For covering connector
Tapping screw
(M5 × 12mm)
4
For mounting decoration
panel
Tapping screw
(M4 × 12mm)
1
For mounting connector
cover
L angle
2
For mounting the Hook
wire to the Decoration
panel
Hook wire
2
For suspending the
Decoration panel
Screw [pitch small]
(M4 x 10mm)
2
For mounting the Hook
wire (for metals)
Screw [pitch large]
(M4 x 10mm)
4
For mounting the L
angle and Hook wire (for
resins)
INDOOR UNIT ACCESSORIES CASSETTE GRILLE ACCESSORIES
