6. SYSTEM DESIGN
ACCESSORY PARTS

Name and shape Q'ty
Installation manual
1
Operating manual
1
Grille
1
Bracket frame
1
Name and shape Q'ty
Screw-A
16
Screw-B
6
Cable clip
2
Cable tie
3
Bushing
1
10 mm
10 mm
- (06 - 147) -
SYSTEM
DESIGN
SYSTEM
DESIGN
