Fujitsu B19-7 LED User Manual

Operation
Adjusting the brightness and contrast
Call up the Brightness/Contrast setting window
Brightness
Set the brightness of th e display
With this function yo u change the brightness of the backgroun d lighting.
Contrast
Set the contrast of the display
With this function you modify the contrast of bright colour tones.
Black level
Set the brightness of th e display
With th is function you modify the contrast of dark colour tones.
Auto level
Adjust the signal level
With this function you can automatically set the contrast.
Thefunctionisexecutedwiththe
button.
If the contrast is set too high, bright surfaces can no longer be d istinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be achieved.
Adjusting the picture size and position
These settings are only possible if the PC is connected analog via VG A.
Call the Image
adjust setting window
Phase
Eliminate picture disturbance
With this function you fine-tune your monitor to eliminate picture disturbance.
Clock
Set synchro
nisation
With this f
unction you adjust the picture width to e liminate vertical picture
disturban
ces.
H-Positi
on
Adjust th
e horizontal position
With this
function you move the picture to the left or to the r igh t.
V-Posit
ion
Adjust t
he vertical position
With th
is f unct ion you move the picture up or down.
Expans
ion
Adjus
t the picture size
Full s
creen = selection of full scree n mode
Keep
aspect = maximum picture size w ithout distortion
26 Fujitsu

Fujitsu B19-7 LED Specifications

General

3D	No
HD type	-
Pixel pitch	0.293 x 0.293 mm
Aspect ratio	5:4
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Supported video modes	480p
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1280 x 1024 (SXGA)
Rotating	Yes
Active display area (W x H)	375 x 300 mm
Mean time between failures (MTBF)	70000 h
Cables included	AC, Audio (3.5mm), DVI, VGA
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
HDMI ports quantity	0
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
RMS rated power	3 W
Number of speakers	2
Sustainability certificates	EPEAT Gold, ENERGY STAR
Certification	CE certification according to EC Directive 2004/108/EEC, EN 60950, RoHS, WEEE, IT-Eco- Declaration, EN 60601-1-2, TÜV GS, EAC, FCC Class B, cUL, VCCI, KC (planned), TÜV-S, S-Mark, BSMI (planned), CCC, SASO, ISO9241-307 (Pixel fault class I), TCO Displays 6.0
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	22 kWh
Power consumption (standby)	- W
Power consumption (typical)	15 W
Power consumption (PowerSave)	0.23 W
Package weight	7200 g
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64
Operating temperature (T-T)	5 - 35 °C
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	209 mm
Height (with stand)	370 mm
Weight (with stand)	5480 g
Depth (without stand)	64 mm
Width (without stand)	414 mm
Height (without stand)	349 mm
Weight (without stand)	2850 g
