Fujitsu B24-8T User Manual

Technical specification
DisplayPort socket
The DisplayPort connection is only available in the model B24-8 TE Pro.
1319 17 15 13 11 9 7 5
2420 19 16 14 12 10 8 6
Pin Meaning
1
Lane 3 (negative)
2Earth
3
Lane 3 (positive)
4
Lane 2 (negative)
5
Earth
6
Lane 2 (positi
ve)
7
Lane 1 (negative)
8Earth
9
Lane 1 (positive)
10
Lane 0 (neg
ative)
11 Earth
12
Lane 0 (positive)
13
Connected to eart h
14
Connec
tedtoearth
15
Auxiliary channel (positive)
16 Earth
17
Auxiliary channel (negative)
18 Hot Plug Detect
19
Re
turn for Power
2
0
Power for connector
(3.3 V 500 mA)
38 Fujitsu
