Fujitsu B24W-6 LED User Manual

Getting started
► Connect one of the connectors of the data cable to the D-SUB socket or the DVI-D socket or the
DP socket of the monitor and secure the plug connection by tightening the retaining screws.
The monitor automatically detects the input when only one signal source is connected.
► Insert one plug of the audio line in the AUDIO IN socket on the monitor
and make sure it is properly eng aged.
► Plug the power cable s upplied into the pow er connector o f the monitor.
► Plug the supplied USB cable into the USB IN socke t and the other end of
the cable into a USB s ocket of the computer.
Connect the USB keyboard a nd USB m ouse directly to the PC, as the USB connector
socket of the monitor is switched off in energy-saving mode.
► Secure th e cove r over the connections.
A lock (Kensington Lock) can be mounted in the security slot to prot ect the m onitor
against theft. A K ensington lock is not supplied with the monitor.
Connecting cables to the computer
Information on th e compu ter connections and interfaces is c onta ined in the
operating m anual for your computer.
► Connect the data cable to the (active) monitor port on the computer and secure
the plug-in connection by tightening the safety screws.
► Insert the o ther plug of the audio cable in the audio output of the computer.
► Plug the power connector of the monitor into a properly grounded mains outlet.
► Plug the power connector of the computer into a properly ground ed mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graph ics card is active as standard.
Fujitsu Technology Solutions 17

Fujitsu B24W-6 LED Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	5
Certification	EN 60950, TÜV GS, GOST, TCO 5.2, FCC B, CE
Product color	Gray
Market positioning	-
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Package weight	8400 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	197 mm
Height (with stand)	395 mm
Depth (without stand)	65 mm
Width (without stand)	559 mm
Height (without stand)	368 mm
Weight (without stand)	6300 g
