Fujitsu B24W-6 LED User Manual

Operation
OSD menu functions
The OSD menu for analogue monitor operation is described below. D uring
digital operation some functions are not available, they are not needed because
of the digital transmission technology being used.
Adjusting the brightness and contrast
Call up the Brightness/Con
trast setting window
Brightness
Set the brightness of the display
With th is function you change the brightness of the background lighting.
Contrast
Set the contrast of the di
splay
With this function you m
odify the c ontrast o f bright colour tones.
Black level
Set the brightness of the display
With this function you mod ify the contrast of dark colour tones.
Auto level
Adjust the signal level
With this function you can automatically set the contrast.
The function is executed with the
button.
If the contrast is set too high, bright surfaces can no longer be distinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be achieved.
Adjusting th
e p icture size and position
Call the Image adjust setting window
Phase
Eliminate picture disturbance
With this function y ou fine-tune you r monitor to eliminate picture disturbance.
Clock
Set synchr oni sation
With this function you adjust the picture width to eliminate v ertical picture
disturbances.
H-Position
Adjust the horizontal position
With this function you move the picture to the left or to the right.
V-Positio n
Adjust the vertical position
With this function you move the picture u p or down.
Expansion
Adjust the picture size
Full screen = selection of full screen mode
Keep aspect = maximum picture size withou t distortion (only for PC image)
Fujitsu Technology Solutions 25

Fujitsu B24W-6 LED Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	5
Certification	EN 60950, TÜV GS, GOST, TCO 5.2, FCC B, CE
Product color	Gray
Market positioning	-
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Package weight	8400 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	197 mm
Height (with stand)	395 mm
Depth (without stand)	65 mm
Width (without stand)	559 mm
Height (without stand)	368 mm
Weight (without stand)	6300 g
