Fujitsu B24W-6 LED User Manual

Troubleshooting
Troubleshooting
Should an error occur, first check the following points. If the distortion is still not eliminated,
the monitor should, if possible, be checked on another comp uter.
If you cannot solve the problem, please contact our Service Desk.
Having this problem? Check the following p oints:
No screen display
Power indicato r does not light up
► Check whether th e power cable on the
monitor is connected correctly.
► Check whether the comput
er is switched on.
No screen display
Powerindicatorislit
► Check whether the computer is switched on.
► Check whether the data cable fo r the
monitor is correctly attached to the monitor
port on the computer.
► Press any key on the comp uter keyboard.
The computer may be in power s aving
mode.
► Alter the brightness and/or contra st until you
get a picture.
Message: No Signal
► Check whether the data cable fo r the
monitor is correctly attached to the monitor
port on the computer.
► Check whether the computer is switched on.
Message:
Frequency out of range:
##kHz/##Hz
Please change the display mode
to 1920 x 1200 with 60 Hz
The input sign
al (ho rizon tal frequency and
refresh rate
) at the displayed input does not
correspond t
o the technical da ta for the monitor.
► Adjust the v
ideo frequency range using the
computer so
ftware ( see documentation for
the compute
r or display adapter).
► Set a different screen resolution using the
computer softw are (see documentation fo r
the computer or display adapter).
Picture position not corre ct
The m onitor recognises an undefined mode (see
chapter "
Technical specification", Page 32).
► Press the
AUTO
button to conduct the
auto-adjustment of the s creen.
Picture is shaking
► Check whether the data cable fo r the
monitor is correctly attached to the monitor
port on the computer.
► Press the
AUTO
button to conduct the
auto-adjustment of the s creen.
Picture is wrongly adjusted
► Run
the Factory Recall function in the OSD
men
u.
The Au to Processing message appea rs.
Picture disturbances (vertical lines)
► Press the
AUTO
button to conduct the
auto-adjustment of the s creen.
Fujitsu Technology Solutions 29

Fujitsu B24W-6 LED Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	5
Certification	EN 60950, TÜV GS, GOST, TCO 5.2, FCC B, CE
Product color	Gray
Market positioning	-
RMS rated power	3 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Package weight	8400 g
Cables included	AC, Audio (3.5mm), DVI, USB, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	197 mm
Height (with stand)	395 mm
Depth (without stand)	65 mm
Width (without stand)	559 mm
Height (without stand)	368 mm
Weight (without stand)	6300 g
