Fujitsu LifeBook S752 Operating Manual

Security functions
Owner Information (device-dependent)
The BIOS feature Owner Informa tion enables you to enter up to 80 characters of text
which is displayed in the bottom left corner of the screen befo re the operating system
boots up. You could use this feature for example to put your name and telephone
number on the notebook in case it is lost or stolen.
Requirements:
• You have been assigned at least the superviso r password.
•IntheBOOT menu, the Boot tim e diagnostic screen option is set to enabled.
► Call up the B IOS Setup a
nd select the Security menu.
► Highlight the Owner Inform ation field and press the Enter key.
► Add the text you would
like to enter under S et Own er Information.

Setup Notice: Changes have been saved is displayed to confirm that the text has been saved.
► From the Exit menu,
choose the option Exit Saving Changes.
► Press the Enter key a nd select Yes.

The notebook will
restart and the Owner Information will be adopted.
Virus Warning (device-dependent)
This field checks the boot sectors of the hard dis k drive to see if any changes have been
made since the previous system start-up. If the boot sector has been changed since the
previous system start-up (e.g. new operating system or v irus attack), a warning is displayed
on the screen. The warning will stay on t he screen until you acknow ledge the changes by
clicking on Confirm o r until you set the Virus Warning function to Disabled.
If the boot sectors have been changed and the reason for this is unknow n, a
programme for finding computer viruses should be loaded.
Such a change is not only caused by viruses, but also by the boot manager.
This function does not replace proper anti-virus software.
No supervisor password is required to set it up.
► Call up the BIOS Se tup and select the Security menu.
► Highlig
ht the Virus Warning field and press the Enter key.
► Select Enabled to activate the Virus Warning function.
► From t
he Exit menu, choose the option Exit Saving Changes.
► Press the Enter key a nd select Yes.

The no
tebook will restart and the settings will be adopted.
58 Fujitsu Technology Solutions

Fujitsu LifeBook S752 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3230M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	26
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
AC adapter included	Yes
Disc types supported	CD, DVD
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA III
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, MS PRO Duo, SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	14 \
Display brightness	220 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Processor code	SR0WX
Processor ARK ID	72056
Processor package size	31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	6 h
Number of battery cells	6
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Cables included	AC
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	GS, CB, FCC, WEEE, CCC
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	245 mm
Width	340 mm
Height	35 mm
Weight	2150 g
