Fujitsu LifeBook S752 Operating Manual

Removing and inst alling components
during servicing
Preparing to remove components
If you are going to remove or change system components, prepare for t he removal as follows:
Please obse rve the safety information in chapter "Important note s", Page 13.
Remove the power plug from the mains outlet !
► Switch the device off.
The device must not be in energy-saving mode !
► Close the LCD screen.
► Remove all the cables
from the d evic e.
► Turn the device over and place it on a stable, flat and clean surface. If necessary, lay an
anti-slip cloth on this surface to prevent the device from being scratched.
► Remov e the battery
(see "
Removing a battery", Page 33 ).
Installing and removing memory expansion
MemorymoduleMainmemoryRemovingmemor
y
Systemexpansi
on
Systemexpansi
on
If you are asked by the Ho tline/Service Desk to remove and install the memory
expansion yourself, proceed as follows:
Please obse rve the safety information in chapter "Important note s", Page 13.
When installing/removing memory modules, the battery must be removed from
the notebook and the notebook must not be connected to the pow er supply,
see "
Preparing to remove components", Page 69.
Only use mem ory expansion modules that have been approved for your
notebook (see "
Technical data", Page 84).
Never use force whe n installing or re moving a memory extension.
Make sure that foreign objects do not fall into the memory extension compartment.
You must open the service compartment t o remove or install a memory module. On some de vices,
opening the compartment may exp ose other components. These components should be removed
and replaced o nly by authorised specialists. Therefore, be sure to observe the following:
Individual components can be come very hot during operation. Therefore, we
recommend that you wait on e hour after switching off the notebook before removing
or installing memory modules. Otherwise, there is a risk of suffering burns!
As some components are exposed that are sensitive to st atic electricity, please take
note of chapter "
Notes on installing and removin g boards and components", Page 68.
Fujitsu Technology Solutions 69

Fujitsu LifeBook S752 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3230M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	26
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
AC adapter included	Yes
Disc types supported	CD, DVD
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA III
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	256 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, MS PRO Duo, SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	14 \
Display brightness	220 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Processor code	SR0WX
Processor ARK ID	72056
Processor package size	31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	6 h
Number of battery cells	6
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Cables included	AC
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	GS, CB, FCC, WEEE, CCC
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	245 mm
Width	340 mm
Height	35 mm
Weight	2150 g
