2-3 FUNCTION AND SETTING OF EACH SWITCH
2-3-1 INDOOR UNIT
02-12
1-2 Room temperature correct coefficient of heating.
Decide the heating temperature correct coefficient value of heating.
2-1 Room temperature correct coefficient of cooling.
Decide the cooling temperature correct coefficient value of cooling.
HEATING TEMPERATURE CORRECTION
Coefficient value
OFF
ON
+ 4 deg
SW1-3
SW1-4
+ 8 deg
OFF
ON OFF
0 deg
OFF
+ 12 degON ON
COOLING TEMPERATURE CORRECTION
Coefficient value
0 deg
SW2-1
ON + 2 deg
OFF
2-2 Dip SW 2-2 setting forbidden
OFF
SW2-2
2-3 Filter check validity / invalidity.
Filter check is set with Dip SW 2-3
FILTER CLEANING FUNCTION
Filter check
Invalidity
SW2-3
ON Validity
OFF
DIP SWITCH SETTING
1. SW1 setting
2. SW2 setting
( Factory setting)
( Factory setting)
( Factory setting)
( Factory setting)
2-4 Auto restart validity / invalidity.
Control the auto restart function by turning this switch ON/OFF.
AUTO RESTART SETTING
Auto restart
Validity
SW2-4
ON
Invalidity
OFF
( Factory setting)
1-1 DIP SW 1-1 and SW 1-2 setting forbidden
OFF
SW1-1
( Factory setting)
OFF
SW1-2
