6. MAINTENANCE, TROUBLESHOOTING
6-8
Advanced troubleshooting (con’t)
Problem
Probable causes or check
points
Remedy
Marks, indications and
noise appear but no echo
(Transmission leak
representing own ship
position is absent)
1) TX high voltage
protection circuit has
activated.
2) Magnetron
3) Modulator board
4) SPU board
1) Reset power to restore normal
operation.
2) Check magnetron current.
Replace magnetron.
3) Replace modulator board.
4) Replace SPU board.
Picture not updated or
picture freeze-up
1) Bearing signal generator
board (in antenna unit)
2) SPU board
3) Video freeze-up
1) Check the connection of signal
cables.
2) Replace SPU board.
3) Turn off and on the radar.
Incorrect orientation of
1) SPU board
2) Gyro interface
1) The message HDG SIG MISSING
appears when the heading pulse is
not received during transmitting.
2) Replace the gyro interface.
Cannot operate radar from
on-screen boxes
SPU Board Replace SPU Board.
Radar is properly tuned but
poor sensitivity
1) Deteriorated magnetron
2) Detuned MIC
3) Dirt on radiator face
4) Water ingress to the
waveguide or other
feeder line
5) Second trace echo
rejection is ON
1) With the radar transmitting on 48 nm
range, check magnetron current.
If current is below normal, magnetron
may be defective. Replace it.
2) Check MIC detecting current. If it is
below normal value, MIC may have
become detuned. MIC must be
tuned.
3) Clean the radiator surface.
4) Remove water from the feeder line.
5) Disable the second-trace echo
rejector referring to section 1.38.
Range changed but radar
picture not changing
1) Defective range key
2) SPU board
3) Video freeze up
1) Try to hit RANGE [+] and [-] keys
several times. If unsuccessful,
replacement of keypad may be
required.
2) Replace SPU board.
3) Turn off and on radar.
(Continued on next page)
