Furuno FELCOM 250 Installation Manual

2. CONNECTIONS
21
2.2 Antenna Cable
Run the antenna cable (coaxial cable 8D-FB-CV, 30 m, 40 m or 50 m supplied) between the an-
tenna unit and communication unit . Attach the connector plug of the antenna cable to the antenna
unit. Connect the coaxial connector (8D-FB-CV) to the other end of the antenna cable.
Wrap the junction point of connectors with the self-adhesive tape then vinyl tape. Bind the ends
of tape with a cable tie (local supply). Fix the cable to the mast with a cable tie (local supply).
Mast
Cable tie
(Weatherproofed)
See the figure below.
[FELCOM 250]
[FELCOM 500]
Cable tie
Inside: Self-adhesive tape
Outside: Vinyl tape
Cable tie
Mouting
Waterprooting the coaxial connector
