8. MAINTENANCE AND TROUBLESHOOTING
8-4
8.3.3 How to show the PV test results
1. Press the F7, 8 and 2 keys to show the PV test results.
2. Long-press the Esc key to return to the standby display.
How to read the PV test results
Test Date & Time: Date and time of test
Attempts: Number of times the PV test was conducted.
BBER: Bulletin Board Error Rate (%). "Pass" appears for no error.
Shore-to-Ship Attempts: Number of tests initiated by LES.
Ship-to-Shore Attempts: Number of tests initiated by MES.
Distress Alert: "Pass (Test OK)" appears for successful testing.
Signal Strength: "Pass" appears if signal strength is greater than standard level.
Overall Result: "Pass" appears for satisfactory completion of the test.
8.4 System Status Monitor
The system status monitor, which is always displayed, provides date, time, equipment
status and navigation data.
Test Date & Time
Attempts
BBER
Shore-to-Ship Attempts
Ship-to Shore Attempts
Distress Alert
Signal Strength
Overall Result
02-02-25 01:58 (UTC)
First attempt
Pass
First attempt
First attempt
Pass (Test OK)
Pass (Greater than Std level + 10dB)
Pass (Applicable tests pass)
Ctrl+P: Print ESC: Quit
PV Test Result
File Edit Transmit EGC Reports Logs Options Setup StopAlarm
Date
Time
Position
Waypoint
Course 345.5 DEG
Speed 10.2 kn
Current NCS
Current Channel
Current TDM
MES Status
GPS Status
DCE Memory
Jan-12-12
01:32 (UTC)
LAT 34:30.00N
LON 135:00.00E
LAT
LON
344 (IOR) LOGOUT
NCS CC
NCS CC
Idle
****
32818 Bytes free
IMN:
BBER
C/N
Send Level
Rx AGC Level
REF Offset Freq
Synthe Local
TCXO Control 131
Antenna Power Supply
Water Temperature
Water Current
Direction
Speed
Depth
443156710
000
OK ( 0 dB)
OK ( 0)
OK (254)
OK ( 0 Hz)
OK
OK(7.vX)
Current State: IDLE
DCE F19 Ver. xx
Retuning
NCS: IOR LOGOUT LAT: 34:30.00N
REC. MESSAGE EXISTS LON: 135:00.00E
Jan-12-12 01:32 (UTC)
68.2 DEG
232 DEG
1.9 kn
xx: Program Version No. of COMMCPU Board
To Next Page
