Engine Setup Number of Engine (1 to 3, 1)
㻌 Engine Assign (1 to 4, 1) Where [Number of Engine] is set to [1]
Engine PORT (1 to 4, 1) Where [Number of Engine] is set to [2] or [3]
Engine STBD (1 to 4, 2) Where [Number of Engine] is set to [2] or [3]
Engine Center (1 to 4, 3) Where [Number of Engine] is set to [3]
Engine Refresh
Scale Range㻌 Speed (0-20kn, 0-40kn, 0-80kn)
㻌 Engine RPM (0-4×1000rpm, 0-6×1000rpm, 0-8×1000rpm)
㻌 Boost (0-30psi, 0-70psi, 0-150psi, 0-360psi, 0-440psi)
㻌 Eng. Temp. (150-250°F, 120-300°F)
㻌 Oil Press. (0-30psi, 0-70psi, 0-150psi, 0-360psi, 0-440psi)
㻌 Oil Temp. (150-250°F, 120-300°F)
㻌 Coolant P (0-30psi, 0-70psi, 0-150psi, 0-360psi, 0-440psi)
㻌 Gear Oil P (0-30psi, 0-70psi, 0-150psi, 0-360psi, 0-440psi)
㻌 Gear Oil T (150-250°F, 120-300°F)
㻌 Voltage (8-16V, 16-32V)
IF-NMEAFI㻌 Select IF
㻌 Category
(Wind, ST800/ST850, Fuel, Fresh Water, Waste Water, Live Well,
Oil, Black Water)
㻌 Resistance Full (0 to 300ohm)
㻌 Resistance Mid (0 to 300ohm)
㻌 Resistance Empty (0 to 300ohm)
㻌 Capacity (0 to 2640gal)
㻌 IF-NMEAFI Test
㻌 Refresh
SC-30 Setup㻌 Select SC
㻌 SBAS Mode (ON, OFF)
SC/SCX Setup Select SC/SCX
SBAS Mode䠄ON䚸OFF䠅
Ship Size/ANT Position㻌 Ship’s Width (1.0 to 999.9 m)
Ship’s Length (1.0 to 999.9 m)
Ship’s Height (1.0 to 199.9 m)
ANT Position X0 (Setting range depends on the
ship’s size information)
ANT Position Y0 (Setting range depends on the
ship’s size information)
ANT Position Z0 (0.0 to 99.9 m)
CAL-SPD-POSN Y1 (Setting range depends on
the ship’s size information)
CAL-SPD-POSN Y2 (Setting range depends on
the ship’s size information)
CAL-SPD-POSN Z (Setting range depends on
the ship’s size information)
System Information
Factory Default
I/O Setup㻌 Incoming PGN
㻌 Device List
㻌 NMEA2000 Refresh
㻌 Wiring Info
ICOM AIS Data (Yes, No)
Data Source㻌 Position
㻌 Heading
㻌 STW
㻌 SOG
㻌 Navigation
㻌 Depth
㻌 W Temp.
㻌 Wind
㻌 AIS
㻌 Heave
㻌 3-Axis Speed
㻌 Roll/Pitch
1
(Continued from previous page)
1
(Continued on next page)
