FURUNO
DFF1-UHD
SP - 1 E2040S01B
140619
SPECIFICATIONS OF NETWORK FISH FINDER
DFF1-UHD
1 GENERAL
1.1 TX frequency 50/200 kHz, alternative transmission
1.2 Output power 1 kW nominal
1.3 Amplifier type Straight amplifier (H/L gain switching available)
1.4 Depth range and Pulse repetition rate (PRR) at 200 kHz, TX rate: 20
Range (m) PRR (times/min, max.)
2 3333
5 2727
10 1622
40 471
100 215
200 112
500 68
1200 31
2 INTERFACE
2.1 I/O port
Network 1 port
Temp/speed sensor 1 port
External KP 1 port (external KP kit: option)
2.2 Network method Ethernet 10Base-T/100Base-TX
3 POWER SUPPLY
3.1 Network fish finder 12-24 VDC: 2.8-1.4 A
3.2 Rectifier (PR-62, option) 100/110/220/230 VAC, 1 phase, 50/60 Hz
4 ENVIRONMENTAL CONDITIONS
4.1 Ambient temperature -15°C to +55°C
4.2 Relative humidity 93% or less at +40°C
4.3 Degree of protection IP55
4.4 Vibration IEC 60945 Ed.4
5 UNIT COLOR
5.1 Network fish finder N2.5 (fixed)
