Furuno NXT-600 User Manual

1
1. INSTALLATION
1.1 Equipment Lists
Standard supply
Optional supply
* : Not compatible with Bottom Discrimination Display and ACCU-FISH
™
features.
Name Type Code No. Qty Remarks
Network Fish Finder DFF1-UHD - 1
Spare Parts SP02-05601 001-033-740 1 set Fuse (2 pcs.)
Installation Materials CP02-08500 000-011-917 1 set - Power cable assy. (3.5 m)
- LAN cable assy. (5 m)
- Self-tapping screws
Name Type Code No. Remarks
Transducer B265LH 000-022-521 1 kW, bronze housing, thru hull
B275LH-W* 000-027-419 1 kW, bronze housing, thru hull, wide beam
CM265LH 000-022-531 1 kW, plastic housing, tank mount
CM275LH-W* 000-027-408 1 kW, plastic housing, tank mount, wide beam
Thru-hull pipe TFB-7000 000-022-532
Tank T-711 000-022-539
Cable Assembly MOD-Z072-020+ 001-167-880-10 2 m, for HUB-101
Cable Assembly MOD-Z072-100+ 001-167-900-10 10 m, for HUB-101
Speed/Tem-
perature Sensor
ST-02MSB 001-164-150-10 Thru-hull mount, steel hull
ST-02PSB 001-164-160-10 Thru-hull mount, plastic hull
Temperature
Sensor
T-04MSB 000-026-893 Thru-hull mount
T-04MTB 000-026-894 Transom mount
Rectifier PR-62 000-013-484 100 VAC
000-013-485 110 VAC
000-013-486 220 VAC
000-013-487 230 VAC
Connector Kit for
TX Sync
OP02-86 001-205-780
